MIA XFHR-600P Premium Commercial ERV
XFHR Series · Premium Commercial

MIA XFHR-600P Premium Commercial ERV + Dehumidifier

高端商用全热交换+除湿一体机 — 600 m³/h cross-flow energy recovery ventilator combined with 80 L/day refrigerant dehumidification in a single ceiling-mount cabinet. BMS-ready with Modbus RTU standard and optional BACnet IP. H13 HEPA + activated carbon — with optional ESP upgrade.

600 m³/h
Airflow Capacity
80 L/day
Dehumidification
BMS Ready
Modbus RTU + BACnet*
≥75%
Heat Recovery Efficiency
Key Features

Technical Highlights

The XFHR-600P integrates ERV, dehumidification, and BMS connectivity into a single ceiling-mounted enclosure — eliminating the need for separate dehumidifier units.

All-in-one Commercial Performance
All-in-one Commercial Performance
600 m³/h cross-flow ERV with 80 L/day refrigerant dehumidification in one ceiling-mount unit. H13 HEPA + activated carbon standard. Optional ESP (electrostatic precipitator) module for sub-micron particle capture. Single installation point, single power connection.
BMS / Modbus / BACnet Integration
BMS / Modbus / BACnet Integration
RS485 Modbus RTU standard — full parameter read/write access: fan speed, setpoints, filter alarms, dehumidifier status, fault codes. Optional BACnet IP gateway module for open-protocol building management systems. Compatible with major BMS platforms including Siemens, Honeywell, and Johnson Controls.
Reinforced 5m Drain Pump
Reinforced 5m Drain Pump
Commercial-grade automatic condensate drain pump with 5m head capacity — eliminates gravity drain constraints in ceiling installations. Dual-pump redundancy available for mission-critical applications. Remote fault alarm via BMS on pump failure or condensate overflow.
Photo Gallery

Product Showcase

XFHR-600P Internal View
XFHR-600P Hero
XFHR-600P Specifications
Models

XFHR-600P — Premium Commercial Unit

Select a model to view full specifications, dimensions, and performance curves.

ERV + Dehumidifier
XFHR-600P
600 m³/h · 80 L/day
View Details →
Specifications

Technical Parameters

XFHR-600P — Premium ceiling-mount ERV + refrigerant dehumidifier. BACnet IP via optional gateway module.

Model Voltage Power Flow Rate Heat Recovery Dehumidification Noise BMS Protocol Weight
XFHR-600P220V/50Hz780W600 m³/h≥75%80 L/day44 dB(A)Modbus RTU + BACnet*~72 kg

* BACnet IP requires optional gateway module. Filtration: H13 HEPA + activated carbon standard; ESP optional. Drain pump: 5m head standard, dual-pump redundancy available on request.

Applications

Applications

Hotel Suites High-end Offices Medical Suites VIP Lounges Luxury Residential
